Our patented elastomer tube folds extend the life of your pinch valves for optimal durability and performance.

Manual Pinch Valves

Play Video
Manual Pinch Valve

Specs

Size Range
1" (25mm) to 60" (1500mm)
Temperature
-50°F to 250°F
Max. Working Pressure
Up to 300psi (20bar) (consult for higher pressures)
Standard Face-to-Face
ASME B-16.10, DIN 3202, ISO 5732
Flange Drilling
ANSI 150#, ANSI 300#, DIN, JIS, AS
Actuation
Manual self-lubricating hand wheel, with or without gear reducer
In-Line Tube Change
Yes
Wear Sensor
Yes, option
Body Type
Enclosed or Sealed
Body Material
Ductile iron (CRN available) or aluminum

Features

  • Sealed & lubricated closing mechanism
  • In-line and quick tube change with patented tube folds for durability & self-cleaning
  • Standard Face-to-Face
  • Exterior & interior corrosion resistant Fusion Bonded Epoxy Powdercoating
