Spartan Controls RailVue™ System is based on three pillars; measurement, service/support and interface/data integration.
Our RailVue™ system is designed specifically for rail terminal loading and unloading applications, it is in full regulatory compliance with American Petroleum Institute (API) Manual of Petroleum Measurement Standards (MPMS) Chapters 5.6, 11, 12, 21, and API RP 3000.

Our RailVue™ system is purpose built to handle all related functions and tasks of railcar loading and unloading from accurate measurement of the products leaving or entering the terminal to integration with external rail logistics. It can provide a complete Bill of Lading (BOL) and transactional data for your field capture and production accounting systems. It incorporates loading target quantity (LTQ) calculations from API RP 3000 to determine the volume or weight limitations to ensure compliance with regulatory quantity requirements for weight and outage. Some of the other functions include accurate density corrected water cuts using Spartan’s AutoComp™ calculation routine, accurate oil and water volumes, industry compliance calculations, real-time data management, metering proving capability, device diagnostics, and audit trails.

A typical RailVue™ panel is capable of handling between 1 and 8 loading arms and can accommodate master meter proving. The system is expandable as well to meet requirements for larger terminals.

You can make just one phone call to access 24/7 support for the whole RailVue™ system including all the end devices. Spartan has experienced factory-trained and fully equipped technicians available to support you through the entire lifecycle of the RailVue™ system with many local offices to serve you.


  • Accurately meter product transfers
  • Provides accurate water cut determination – for meeting pipeline specifcations (±0.5%)
  • Accurately measure mass, density and volumes
  • AutoComp proprietary rule-based software routines to provide automated real- time oil densities
